MKIV Unit 2 Furling System


MKIV Unit 2 Furling System

3,712.00

MKIV furling systems are strong, lightweight and aerodynamic, with the performance and features Harken® is known for. Longevity, ease of use, and simplicity of installation are crucial components of the design.

Product Number: 7412.10

Typical Boat Length: 35-46' (10.6-14.2 m)
Wire: 5/16, 3/8" (8, 10 mm)
Rod: -12, -17, -22 (7.14, 8.38, 9.53 mm)
Clevis Pin: 5/8, 3/4" (15.9, 19.1 mm)
Standard Headstay Length: 60' 4" (18.38 m)
Max Headstay Length: 67' 4" (20.51 m)

* Additional equipment required.

Quantity:
Add To Cart

A: 5 5/8" (143 mm)
B: 9 1/8" (231 mm)
C Max.: 16" (406 mm)
D: 2 9/16" (66 mm)
E Max.: 51 3/4" (1,314 mm)
E Min.: 46 3/4" (1,187 mm)
F Max.: 15 1/8" (384 mm)
F Min.: 12 1/16" (306 mm)
G Max.: 13 15/16" (348 mm)
G Min.: 10 7/8" (276 mm)
H: 8 3/16" (208 mm)
I: 3 13/16" (97 mm)
J Max.: 3 13/16" (164 mm)
J Min.: 3 3/8" (85 mm)
K: 1 1/4" (32 mm)
L: 1 3/8" (36 mm)
Extrusion Length: 7' (2.13 m)

DO NOT use Harken equipment for human suspension unless product is specifically certified and labeled for such use.


Assemblies for MKIV Unit 2


Optional Parts for MKIV Unit 2
