MKIV Unit 0 Furling System


MKIV Unit 0 Furling System

1,704.00

MKIV furling systems are strong, lightweight and aerodynamic, with the performance and features Harken® is known for. Longevity, ease of use, and simplicity of installation are crucial components of the design.

Product Number: 7410.10

Typical Boat Length: 22'-30' (6.5
Wire: 5/32, 3/16, 7/32" (4, 5, 6 mm)
Rod: -4, -4 (4.37, 5.03 mm)
Clevis Pin: 5/16, 3/8, 7/16" (7.9, 9.5, 11.1 mm)
Standard Headstay Length: 38' 7" (11.77 m)
Max Headstay Length: 45' 7" (13.9 m)

* Additional equipment required.

Quantity:
Add To Cart

A: 3 3/4" (96 mm)
B: 5 7/8" (150 mm)
C Max.: 9/78" (250 mm)
D: 1 7/8" (47 mm)
E Max.: 41" (1,041 mm)
E Min.: 39 1/2" (1,003 mm)
F Max.: 8 3/8" (213 mm)
F Min.: 8 1/4" (209 mm)
G Max.: 7 5/16" (186 mm)
G Min.: 7 3/16" (183 mm)
H: 5 1/2" (140 mm)
I: 2 5/8" (66 mm)
J Max.: 2 5/16" (59 mm)
J Min.: 2 3/16" (56 mm)
K: 7/8" (23 mm)
L: 1 1/32" (26 mm)
Extrusion Length: 7' (2.13 m)
